Key Specifications

I/O

• Input: 1x SDI (switchable between SD, HD & 3Gbs)
• Output: 1x component, NTSC, PAL, and S-video; 1x SDI (loop output)

Audio

• Analog: 2 channels of balanced analog audio with 1/4" jack connections
• Digital: 2 channels of balanced digital audio with 1/4" jack connections (AES/EBU standard)

Power & Physical

• Power: 12VDC
• Power Consumption: 8.04 Watts
• Dimensions: 4.84 x 3.63 x 0.90" / 12.29 x 9.22 x 2.29 cm
• Weight: 8.36 oz / 237 g

Features & Standards

• Reclocking: Yes
• Video Compliance: SMPTE 292M, 259M, 296M, 372M, 424M-B, 425M, ITU-R BT.656, and BT.601
• Format Conversion: HD to SD down converter
