Key Specifications

Video Input / Output

SDI Input

1 × 3G/HD/SD-SDI (Auto-Selecting, Level A & B Supported)

HDMI Output

1 × HDMI Type-A

SDI Loop Output

1 × 3G/HD/SD-SDI

SDI Format Support

Supported Formats

1080p @ 50/59.94/60 fps
1080psf @ 23.98/24/25/29.97/30 fps
1080p @ 23.98/24/25/29.97/30 fps
1080i @ 50/59.94/60 fps
720p @ 24/25/30/50/59.94/60 fps
625i @ 50 fps
525i @ 59.94 fps

SDI Compliance

SMPTE 292M / SMPTE 259M / SMPTE 424M

SDI Color Space

YUV 4:2:2

HDMI Format Support

Supported Formats

1080p @ 50/59.94/60 fps
1080p @ 23.98/24/25/29.97/30 fps
1080i @ 50/59.94/60 fps
720p @ 24/25/30/59.94/60 fps
576i @ 50 fps
480i @ 60 fps

HDMI Color Space

YUV 4:2:2

Power

Power Port

1 × Micro-USB

Power Consumption

1.5 W

Voltage Range

3.3 – 5 V

Environmental

Operating Temperature

-20 to 60°C (-4 to 140°F)

Storage Temperature

-30 to 70°C (-22 to 158°F)

Relative Humidity

0 to 90% (Non-Condensing)

Physical Specifications

Dimensions

7.4 × 4.1 × 2.3 cm (2.9 × 1.6 × 0.9")

Packaging Information

Package Weight

0.83 lb

Box Dimensions (L × W × H)

4.6 × 3.3 × 3.1"
