Key Specifications

Code

31761

Configuration

2-Way

Amplifier

Built-In Amplifier (LF/HF)

600 W / 300 W RMS

Built-In Amplifier Peak (LF/HF)

1200 W / 600 W

AC Power Requirements

640 VA

Power Cord

5 m (16.4 ft)

Audio Performance

Frequency Response

60 Hz – 20 kHz (-6 dB)

Maximum SPL

127 dB Continuous / 134 dB Peak

Dispersion

70° Conical (H × V)

Input Impedance

22 kΩ

Drivers

Low Frequency Woofer

2 × 10" Woofer with 2.5" Voice Coil

High Frequency Driver

1.4" Driver with 2.5" Voice Coil

Connectivity

Input Connector

XLR with Loop Output

Physical Specifications

Dimensions (W × H × D)

547 × 280 × 402 mm (22.6 × 11 × 15.8 in)

Net Weight

17.8 kg (39.2 lb)

Packaging Information

Transport Dimensions (W × H × D)

515 × 685 × 395 mm (20.2 × 26.9 × 15.5 in)

Transport Weight

21 kg (46.2 lb)
