Key Specifications

Number of Analog Input Channels

8 (2 Mono / 2 Stereo)

Number of Mic Preamps

2

Analog Output Channels

1x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono Aux Send Output
1x Stereo Tape/Record Output
1x Stereo Headphone Output

Mix Routing

Main Mix per Mono Input Channel, Stereo Input Channel
Stereo Aux Bus/Subgroup per Stereo Input Channel

EQ

3-Band EQ

Built-In Effects

No

Wireless

No

Rack Mountable

No

Mixer

Number of Analog Input Channels

8 (2 Mono / 2 Stereo)

Number of Mic Preamps

2

Analog Output Channels

1x Stereo Master Output
1x Stereo Control Room/Monitor Output
1x Mono Aux Send Output
1x Stereo Tape/Record Output
1x Stereo Headphone Output

Mix Routing

Main Mix per Mono Input Channel, Stereo Input Channel
Stereo Aux Bus/Subgroup per Stereo Input Channel

Faders & Level Adjustment

4x Channel Knob
1x Bus/Subgroup Knob
1x Master Knob

Meters

1x 4-Segment LED

Signal Processing

Gain/Trim Range

Up to +10 dB

Sidechain Filters

No

EQ

3-Band EQ

EQ Parameters

High: ±15 dB at 12 kHz (Shelving)
Mid: ±15 dB at 2.5 kHz (Notch/Peak)
Low: ±15 dB at 80 Hz (Shelving)

Graphic EQ

No

Filters

Low-Pass: 75 Hz, 18 dB/Octave

Solo/Mute

No

Built-In Effects

No

Performance

Frequency Response

Mic Input to Output:
20 Hz to 30 kHz +0/-1 dB (Unity Gain)

Max Input Level

XLR Mic Input:
+19 dBu
Aux Return:
+16 dBu
Line Input:
+21 dBu

I/O Impedance

Mic Input:
3.8 Kilohms

Line Input:
≥ 10 Kilohms

Tape Output:
1 Kilohms

Headphone Output:
22 Ohms

Main Output:
120 Ohms (Unbalanced)
240 Ohms (Balanced)

Crosstalk

Input to Output:
-85 dB at 1 kHz (20 Hz to 20 kHz)
Master Fader Off:
-75 dB at 1 kHz

CMRR

> -70 dB at Max Gain (1 kHz, Mic In to Insert Send Out)

EIN

-125 dBu at Max Gain

Noise Floor

All Outputs:
-100 dBu (Master Level at -∞, Channel Levels at -∞)
-90 dBu (Master Level at Unity, Channel Levels at -∞)
-85 dBu (Master Level at Unity, One Channel Level at Unity)

THD+N

Mic Input to Main Output:
< 0.25% (+4 dBu)

Connectivity

Analog Inputs

2x XLR 3-Pin Balanced/Unbalanced Mic Input
2x 1/4" TRS Balanced/Unbalanced Line Input
4x 1/4" TRS Balanced/Unbalanced Stereo Line Input (2 Stereo Pair)
2x 1/4" TRS Balanced/Unbalanced Aux Return
1x Stereo RCA Coaxial Unbalanced Tape Input (1 Stereo Pair)

Analog Outputs

2x 1/4" TRS Balanced/Unbalanced Stereo Main Output (1 Stereo Pair)
1x 1/4" TRS Mono Aux Send
1x 1/4" TRS Stereo Headphone Output
1x Stereo RCA Coaxial Unbalanced Stereo Tape Output (1 Stereo Pair)
1x Stereo RCA Coaxial Unbalanced Stereo Tape Output (1 Stereo Pair)

Phantom Power

No

Digital I/O

No

Wireless

No

Power

AC Input Power

120 VAC, 60 Hz
230 VAC, 50 / 60 Hz

Power Supply Output

18 VAC at 1000 mA

Physical

Rack Mountable

No

Dimensions

2.1 x 7.8 x 9.6" / 53 x 198 x 244 mm

Weight

2.5 lb / 1.1 kg

Packaging Info

Package Weight

3.285 lb

Box Dimensions (LxWxH)

13.4 x 9.3 x 3.4"
