Key Specifications

Microphone Input

Type: Electret Condenser
Gain Range: +15 to +55 dB
Sensitivity: -42 dB

Stereo Input

Type: 1/4" TRS Active Balanced
Input Impedance: 10 kΩ (Balanced)
S/N Ratio: >105 dB (1 kHz @ +10 dBu, Unity Gain)
THD+N: <0.0075% (1 kHz @ 0 dBu Output, Unity Gain)
Frequency Response: 10 Hz to 65 kHz (±0.5 dB)
Noise Floor: -96 dBu (20 Hz–20 kHz, 150Ω Termination)
Maximum Input Level: +22 dBu (Min Gain, 1 kHz @ 0.5% THD+N)

AUX Inputs

Type: RCA Active Unbalanced
Input Impedance: 47.5 kΩ
S/N Ratio: >115 dB (1 kHz @ 0 dBu, Unity Gain)
THD+N: <0.01% (1 kHz @ 0 dBu Output, Unity Gain)
Frequency Response: 10 Hz to 50 kHz (±0.5 dB)
Gain Range: -80 dB to +10 dB

S/PDIF Input

Type: RCA 75Ω Coaxial
Dynamic Range: 113 dB
THD+N: 0.0025% (1 kHz @ -1 dBFS)
Maximum Output: +18 dBu @ 0 dBFS
Sample Rates: 44.1, 48, 88.2, 96 kHz

Input Meters

Type: Dual 8-Segment LED with Peak Hold
Sensitivity Range: -24 dB to 0 dB

Analog Outputs

Type: 1/4" TRS Active Balanced
Output Impedance: 51Ω (Balanced)
THD+N: <0.01% (1 kHz @ 0 dBu, Unity Gain)
Frequency Response: 10 Hz to 50 kHz (±0.5 dB)

Speaker Output Control

Trim Range: -80 dB to 0 dB
Main Level Range: -80 dB to 0 dB
Dim Attenuation Range: -30 dB to -6 dB

Cue Output

Cue Level Range: -80 dB to 0 dB
Dim Attenuation (Talkback Active): -20 dB

Headphone Outputs

Type: 1/4" TRS Active Stereo
Maximum Output: 150 mW per Channel (60Ω Load)
Frequency Response: 10 Hz to 50 kHz (±1.0 dB)

Power Supply

Type: External DC Transformer / Internal Regulation
Input Connector: Barrel (5.5 mm OD / 2.1 mm ID)
Input Voltage: 18 VDC
Power Consumption: 10 W (Continuous)

Dimensions (HxWxD)

2.5 × 8.5 × 9.0" / 63.5 × 216.0 × 228.6 mm

Net Weight

6 lb / 4.54 kg

Package Weight

5.165 lb

Box Dimensions (LxWxH)

17 × 12.1 × 5"
