Key Specifications

Frequency Response (-10 dB)

70 Hz - 20000 Hz

Max SPL @ 1m

112 dB

Coverage Angle

120° (Conical)

System Sensitivity

91 dB

Power Section

Power Handling

60 W RMS / 240 W PEAK

Nominal Impedance

16 Ω

Crossover Frequency

3000 Hz

Recommended Amplifiers

DMA 504, DMA 162, AM 2320, UP 2321 (and similar 100V amps)

Transducers

Dome Tweeter

1 x 1.0'' Neodymium

Woofer

1 x 5.0'' Neodymium

Input / Output Section

Constant Voltage Transformer

100 V

Power Selection (100V Taps)

30 W, 20 W, 10 W, 5 W

Connectors

Euroblock (In/Out)

Physical Specifications

Cabinet Material / Grille

Self-extinguishing Plastic / Steel

Color Options

White (RAL 9016), Black (RAL 9005)

Dimensions (Dia x D)

266 x 156 mm / 10.47 x 6.14 inches

Recessed Depth / Cut-out

140 mm (5.51") / 245 mm (9.65")

Weight

2.1 kg / 4.63 lbs

Shipping Information

Package Dimensions

235 x 310 x 310 mm / 9.25 x 12.2 x 12.2 inches

Package Weight

2.99 kg / 6.59 lbs
