Key Specifications

Frequency Response (-10 dB)

100 Hz - 20000 Hz

Max SPL @ 1m

114 dB

Coverage Angle (H x V)

90° x 60°

System Sensitivity

94 dB

Power Section

Power Handling

60 W RMS / 240 W PEAK

Nominal Impedance

8 Ω

Constant Voltage Transformer

100 V

Power Selection (Taps)

30 W, 20 W, 10 W, 5 W

Crossover Frequency

3000 Hz

Recommended Amplifiers

UP 2321, UP 2162

Transducers

Dome Tweeter

1 x 1.0''

Woofer

1 x 5.0''

Standard Compliance

IP Protection Grade

IP 55

Safety Agency

CE compliant

Physical Specifications

Cabinet Material

Plastic

Hardware

Wall mount bracket

Color Options

White (RAL 9016), Black (RAL 9005)

Dimensions (H x W x D)

223 x 191 x 236 mm / 8.78 x 7.52 x 9.29 inches

Weight

3.65 kg / 8.05 lbs

Shipping Information

Package Dimensions

285 x 305 x 250 mm / 11.22 x 12.01 x 9.84 inches

Package Weight

4.36 kg / 9.61 lbs
