Key Specifications

System Type

• Design: Active 12” bass reflex
• LF: 12” woofer (3” voice coil)
• HF: 1” exit driver (1.77” voice coil)

Audio Performance

Acoustics

• Frequency Response: 60Hz to 20KHz
• Max SPL: 122 dB SPL @ 1m
• Coverage Angle: 70° x 40°
• Crossover Frequency: 2.5KHz

Amplification & I/O

• Amp Power: 600W Class-D Amplifier
• Inputs: Balanced XLR Line Input
• Outputs: Balanced XLR Link Output
• AC Power: 220V 50/60Hz

Physical Specifications

Dimensions & Weight

• Dimension (HxWxD): 450 x 465 x 330 mm
• Net Weight: 21.5 kg
• Gross Weight: 23 kg

Shipping Information

• Packaging Size: 520 x 540 x 390 mm
