Key Specifications

System Type

• Design: Active 15” bass reflex
• LF: 15” woofer (3” voice coil)
• HF: 1” exit driver (1.77” voice coil)

Audio Performance

Acoustics

• Frequency Response: 60Hz to 20KHz
• Max SPL: 124 dB SPL @ 1m
• Coverage Angle: 70° x 40°
• Crossover Frequency: 2.3KHz

Amplification & I/O

• Amp Power: 600W Class-D Amplifier
• Inputs: Balanced XLR Line Input
• Outputs: Balanced XLR Link Output
• AC Power Input: 220V 50/60Hz

Physical Specifications

Dimensions & Weight

• Dimension (HxWxD): 520 x 495 x 345 mm
• Net Weight: 24 kg
• Gross Weight: 26 kg

Shipping Information

• Packaging Size: 635 x 590 x 440 mm
