Key Specifications

Monitor Type & Configuration

Active Full-Range

Total Power Output

30 W RMS

Full Range Drivers

1 × 4" / 10.1 cm Cone, Voice Coil: 1" / 25.4 mm

Frequency Range

77 Hz – 20 kHz

Audio I/O

Analog Inputs

1 × Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input (5.4 kΩ)
1 × 1/8" / 3.5 mm TRS Unbalanced Line Input (10 kΩ)
1 × 1/4" TRS Balanced/Unbalanced Line Input (10 kΩ)

Analog Outputs

1 × 1/4" TRS Balanced/Unbalanced Line Output

Digital Audio I/O

No

Network I/O

No

Wireless

No

Enclosure

Type

Bass-Reflex / Ported, Shielded

Amplifier

Full-Range: 30 W RMS Class-D

Performance

Maximum SPL

115 dB

Analog Input Sensitivity / Gain

-10 dBu

Signal Processing

EQ

1 × HF Shelf, 1 × LF Shelf

Filters

No

Phase Adjustment

No

Power

AC Input Power

100–240 VAC, 50/60 Hz

Power Consumption

3 W (Idle), 10 W (Typical)

Physical

Color

Black

Monitor Orientation

Vertical

Mounting Points

2 × M5 (Bottom Panel)

Dimensions (W × H × D)

5.6 × 7.7 × 7.4" / 14.2 × 19.6 × 18.7 cm

Weight

4.6 lb / 2.1 kg

Packaging Info

Package Weight

6.67 lb

Box Dimensions (L × W × H)

13.2 × 11.1 × 9.8"
