MSP3A
MSP3A
YAMAHA
UNIT: PIECE/S
Product Code: SKU:YAMH-MSP3A-CHN-533
Key Features
YAMAHA MSP3A
YAMAHA MSP3A
Key Specifications |
|
Monitor Type & Configuration |
Active 2-Way |
Total Power Output |
22 W |
Drivers |
|
Tweeter |
1 × 0.8" / 20 mm Dome |
Woofer |
1 × 4" / 10.2 cm Cone |
Amplifiers |
Full-Range: 22 W Class-AB |
Performance |
|
Frequency Range |
67 Hz – 22 kHz |
Maximum SPL |
99 dB |
Total Harmonic Distortion (THD) |
0.1% |
Analog Input Sensitivity / Gain |
+4 dB to -10 dBu |
Crossover Frequency |
4 kHz |
Connectivity |
|
Audio I/O |
1 × RCA Unbalanced Line Input (10 kΩ) |
Digital Audio I/O |
No |
Network I/O |
No |
USB |
No |
Wireless |
No |
Mobile App Compatible |
No |
Power |
|
AC Input Power |
110–120 VAC, 50/60 Hz |
Power Consumption |
30 W |
Physical |
|
Color |
Black |
Monitor Orientation |
Vertical |
Mounting Points |
2 × M5 (Bottom Panel) |
Dimensions (W × H × D) |
5.7 × 9.3 × 6.5" / 14.4 × 23.6 × 16.6 cm |
Weight |
7.9 lb / 3.6 kg |
Packaging Info |
|
Package Weight |
10.675 lb |
Box Dimensions (L × W × H) |
13.7 × 9 × 8.3" |
YAMAHA MSP3A Accessories
- No accessories available.
