Key Specifications

Microphone Type

Boundary (Surface Mount)

Polar Pattern

Cardioid

Element Type

Electret Condenser

Frequency Response

50 Hz to 17 kHz

Maximum SPL

119 dB (1 kHz at 1% THD)

Analog Output

1x XLR 3-Pin Male (Attached Preamp)

Power Sources

Phantom Power

Microphone

Sound Field

Mono

Cable Length

12.1' / 3.7 m (Attached)

RF Immunity

CommShield Technology

Connector at Mic

4-Pin Mini Connector (TA4F)

Performance

Sensitivity

-30 dBV/Pa (32 mV) at 1 kHz

Dynamic Range

96.2 dB (1 kΩ load)

Signal-to-Noise Ratio

71 dB (Ref. 94 dB SPL)

Equivalent Noise Level

23 dB SPL (A-Weighted)

Power

Operating Voltage

11 to 52 VDC (Phantom Power)

Current Consumption

2.0 mA

Physical

Color

Black / White

Dimensions (H x W x L)

0.75 x 2.09 x 3.13" / 19 x 53 x 79 mm

Weight

4.44 oz / 126 g

Packaging Info

Package Weight

1.05 lb

Box Dimensions (LxWxH)

10.2 x 5 x 3.3"
