Key Specifications

Hum & Noise

<-80 dB @ 20 Hz~22 kHz A-weighted, 1 channel & main level: 0 dB, the other: minimum

Crosstalk

<-80 dB @ 0 dB 20 Hz~22 kHz A-weighted, main level: 0 dB, the other: minimum

Frequency Response

Mic/Line Input to any output: 20 Hz–20 kHz <1 dB

THD + N

Mic sensitivity -30 dBu, +20 dBu at all outputs @ 1 kHz: <0.006%

CMRR

Typical @ max gain @ 1 kHz: >80 dB
Typical @ any gain @ 50 Hz: >60 dB

Input & Output Impedance

Mic Input

1.8 kΩ

Line Input

23.6 kΩ

Stereo Input

20 kΩ

Mix, Aux and Insert Sends

120 Ω

Input & Output Levels

Mic Input max. level

+20 dBu

Line Input max. level

+30 dBu

Stereo Input max. level

+30 dBu

Headphones (@ 200 Ω)

150 mW

Compressor

Gain

0 - 9 dB

Threshold

20 dB →↓5 dB

USB 2.0 (Standard B)

Inputs / Outputs

2-in, 2-out

Bit Depth

16-bit

Sampling Rate

32 kHz / 44.1 kHz / 48 kHz

USB Player

Direct playback / record from USB flash drive, 2-in / 2-out, Record sampling rate: 44.1 kHz

Power Consumption

Mains Voltage

100–240 VAC, 50/60 Hz, universal input

Physical

Net Weight

6.59 kg

Gross Weight

8.2 kg

Dimensions (L×W×H)

504.62 x 425.00 x 88.34 mm
