Key Specifications

Product / Accessory Type

Digital Home Console Piano with Triple Pedal Assembly

Power Management

Auto-Off Power Saving Function

Keyboard & Keybed Action Specifications

Keyboard Assembly & Action Type

NUX WKJ-03 Triple-Sensor Scaled Hammer-Action Weighted Keyboard

Keybed Mechanism & Escapement

Simulated Escapement Mechanism

Touch Sensitivity / Dynamics

5 Selectable Velocity Response Levels

Tone Generation, DSP & Audio Processing

Onboard Sound Engine & Tones

143 Total Tones (15 Dedicated Acoustic/Electric Piano Tones, 128 General Instrument Tones)

Maximum Polyphony

256 Notes

Keyboard Performance Modes

Layered Sounds (with Adjustable Volume Balance);
Split Keyboard (Adjustable Split Point with Independent Tone Selection, Octave Shift & Volume Controls)

Integrated DSP Effects & EQ

Reverb: 3 Types (Adjustable Depth 0 to 100);
Chorus: Adjustable Depth (0 to 100);
Brightness: Adjustable Level (0 to 100);
Speaker EQ: 3 Preset Acoustic Curves

Pedal Unit & Assignable Controls

Pedal Assembly

Integrated 3-Pedal Unit with Half-Pedal Damper Support

Assignable Pedal Functions

Damper, Soft, Sostenuto, Modulation, Master Volume, Pitch Up, Pitch Down

Accompaniment, Performance & Practice Functions

Pianist Auto-Accompaniment

50 Pianist Accompaniment Styles (Single / Multi-Fingering Auto Chord Detection, Sync Start)

Transpose & Tuning Controls

Transpose: -12 to +12 Semitones (±1 Octave);
Master Tuning (A4): 425.0 Hz to 455.0 Hz

Metronome, Recording & Memory

Metronome: 40 to 240 BPM (9 Time Signatures, 4 Metronome Tones);
Internal Song Recorder: 5 Tracks;
User Presets: 5 Memory Locations;
Demo Songs: 100 Preset Songs

Amplification & Speaker System Specifications

Amplifier Output Power

20 W Total RMS Power Output (2x 10 W Output Channels)

Loudspeaker Transducers

2x 127.00 mm (5.00") Custom Full-Range Speakers

Connectivity & Interface Specifications

Wireless Connectivity

Bluetooth Audio Streaming & Bluetooth MIDI (via NBT-1 Module Interface)

Analog Audio Outputs

Line Output: 2x 1/4" (6.35 mm) L/MONO & R Output Jacks;
Headphone Outputs: 1x 1/4" (6.35 mm) Stereo Headphone Jack & 1x 1/8" (3.5 mm) Stereo Headphone Jack

Analog Audio Input

Auxiliary Input: 1x 1/8" (3.5 mm) Stereo Aux In

Pedal & Module Ports

Pedal Assembly Port, NBT-1 Bluetooth Adapter Expansion Jack

Digital Data Interface

USB Type-B (USB MIDI Communication & USB Audio Streaming with Adjustable Recording Level)

Power & Electrical Specifications

Operating Power Requirements

12 VDC, 2 A External Power Supply Adapter

Dimensions & Weight Specifications

Product Dimensions (L×W×H)

1,366.00 mm x 361.00 mm x 791.00 mm (53.78" x 14.21" x 31.14")

Product Net Weight

37.90 kg (83.55 lbs)
