Key Specifications

Product / Accessory Type

61-Key Portable Arranger Keyboard with Pitch Bend Wheel

User Interface Display

TFT LCD Screen (128 x 64 dpi Resolution)

Included Accessories

Power Adapter, Music Rest, User Manual, NBT-1 Bluetooth Module

Keyboard & Performance Control Specifications

Keyboard Assembly & Key Count

61 Keys

Touch Sensitivity / Dynamics

5 Selectable Velocity Curves (Light 2, Light 1, Normal, Hard 1, Hard 2)

Pitch Bend Controller

Integrated Pitch Bend Wheel (±2 Semitones Range)

Tone Generation, DSP & Audio Processing

Onboard Tones & Sound Library

700 Preset Tones

Maximum Polyphony

54 Notes

Voice Layering & Performance Modes

Triple Voice Layering, Split Keyboard Function

DSP Effects & Tuning Controls

40 Reverb/Effect Types, Master Tuning (A4 = 420.0 Hz to 460.0 Hz)

Accompaniment & Performance Functions

Auto-Accompaniment System

100 Styles (Auto Chord, Sync Start, Intro / Ending, Main A/B Variations, Main/Fill A/B Variations)

Live Music Performance Mode

40 Live Music Interactive Songs

Transpose & Octave Shift

Transpose: -12 to +12 Semitones (±1 Octave);
Octave Shift: -1 to +1 Octaves

Demo Songs, Metronome & Presets

Demo Songs: 100 Songs;
Metronome: 40 to 240 BPM (9 Beats, 4 Voice Options);
User Presets: 9 Memory Locations

Amplification & Speaker System Specifications

Amplifier Output Power

10 W Total RMS Output (2x 5 W Channels)

Loudspeaker Transducers

2x 55.88 mm x 124.46 mm (2.20" x 4.90") Drivers

Connectivity & Interface Specifications

Wireless Connectivity (via Included NBT-1 Module)

Bluetooth Audio Streaming & Bluetooth MIDI

Analog Audio Outputs

Line Output: 1x 1/4" (6.35 mm) Stereo Aux Output;
Headphone Output: 1x 1/8" (3.5 mm) Stereo Phones Output

Analog Audio Input

Auxiliary Input: 1x 1/8" (3.5 mm) Stereo Aux Input

Pedal Interface

1x 1/4" (6.35 mm) Sustain Pedal Jack

Digital Data Interface

USB Type-B (USB MIDI & USB Audio Streaming)

Power & Battery Specifications

Power Supply Options

Internal Rechargeable Battery (3,000 mAh Capacity), or External DC 12 V / 2 A Center-Positive Power Adapter

Dimensions & Weight Specifications

Product Dimensions (L×W×H)

925.00 mm x 252.00 mm x 80.00 mm (36.42" x 9.92" x 3.15")

Product Net Weight

3.10 kg (6.83 lbs)
