Key Specifications

Number of Analog Input Channels

12 (4 Mono / 4 Stereo)

Number of Mic Preamps

4

Analog Output Channels

1x Stereo Master Output
1x Mono Aux Send Output
1x Stereo Headphone Output

Mix Routing

Stereo Main Mix

EQ

3-Band EQ

Built-In Effects

Delay
Chorus
Reverb

USB I/O

1x USB-B

Wireless

No

Rack Mountable

No

Mixer

Number of Analog Input Channels

12 (4 Mono / 4 Stereo)

Number of Mic Preamps

4

Analog Output Channels

1x Stereo Master Output
1x Mono Aux Send Output
1x Stereo Headphone Output

Mix Routing

Stereo Main Mix

Faders & Level Adjustment

No

Meters

Main Meter: 2x 4-Segment LED

Meter Range

-20 dB to +6 dB Plus Peak/Clip

Signal Processing

Gain / Trim Range

10 to 58 dB

Input Pad

-20 dB

EQ

3-Band EQ

EQ Parameters

High: ±12 dB at 12 kHz
Mid: ±12 dB at 2.5 kHz
Low: ±12 dB at 80 Hz

Graphic EQ

No

Built-In Effects

Delay
Chorus
Reverb

Performance

Frequency Response

20 Hz to 20 kHz ±1.5 dB

Max Input Level

Mic Input: +11 dBu
Line Input: +30 dBu
Hi-Z Input: +17 dBu
Stereo Input: +22 dBu

Crosstalk

21.5 dBu (1 kHz)

EIN

< 127 dBu

Noise Floor

-98 dBu

Connectivity

Analog Inputs

4x Combo XLR-1/4" Mic/Line Input
4x 1/4" Line Input
1x Stereo RCA Coaxial Line Input
2x 1/4" Line/FX Input

Analog Outputs

2x XLR 3-Pin Main Output (1 Stereo Pair)
1x 1/4" Aux Output
1x 1/4" TRS Headphone Output

Phantom Power

Yes

Digital I/O

No

MIDI I/O

No

USB I/O

1x USB-B
USB I/O Capacity: 4x Input / 4x Output

Wireless

No

Compatibility

OS Compatibility

No

Physical

Rack Mountable

No

Packaging Info

Package Weight

4.705 lb

Box Dimensions (L × W × H)

13.6 x 12.05 x 3.6"
