Key Specifications

Number of Analog Input Channels

5 (1 Mono / 2 Stereo)

Number of Mic Preamps

1

Analog Output Channels

1x Stereo Master Output
1x Mono Aux Send Output
1x Stereo Headphone Output

Mix Routing

1x Stereo Main Mix

EQ

2-Band Shelving (Mono Channels)

Built-In Effects

No

USB I/O

1x USB-B

Wireless

No

Rack Mountable

No

Mixer

Max I/O Capacity

5x Input / 2x Output

Number of Analog Input Channels

5 (1 Mono / 2 Stereo)

Number of Mic Preamps

1

Analog Output Channels

1x Stereo Master Output
1x Mono Aux Send Output
1x Stereo Headphone Output

Mix Routing

1x Stereo Main Mix

Faders & Level Adjustment

3x Channel Knob
1x Master Knob

Meters

Main Meter: 2x 4-Segment LED

Signal Processing

EQ

2-Band Shelving (Mono Channels)

EQ Parameters

Mono Channels:
High: ±12 dB at 12 kHz
Low: ±12 dB at 80 Hz

Graphic EQ

Yes

Built-In Effects

No

Connectivity

Analog Inputs

1x Combo XLR-1/4" Mic/Line Input
2x 1/4" Line Input
1x Stereo RCA Line Input

Analog Outputs

2x XLR 3-Pin Main Output (1 Stereo Pair)
1x 1/4" Monitor Output

Phantom Power

Yes

Digital I/O

No

MIDI I/O

No

USB I/O

1x USB-B

Wireless

No

Compatibility

OS Compatibility

macOS / Windows

Power

DC Input Power

18 VDC at 1.3A

Physical

Rack Mountable

No

Packaging Info

Package Weight

2.265 lb

Box Dimensions (L × W × H)

10.35 x 8.95 x 3.55"
