Key Specifications

Number of Analog Input Channels

8 (2 Mono / 3 Stereo)

Number of Mic Preamps

2

Analog Output Channels

1x Stereo Master Output
1x Mono Aux Send Output
1x Stereo Headphone Output

Mix Routing

1x Main Mix

EQ

3-Band EQ

Built-In Effects

Delay
Chorus
Reverb

USB I/O

1x USB-B

Wireless

No

Rack Mountable

No

Mixer

Max I/O Capacity

8x Input / 3x Output

Number of Analog Input Channels

8 (2 Mono / 3 Stereo)

Number of Mic Preamps

2

Analog Output Channels

1x Stereo Master Output
1x Mono Aux Send Output
1x Stereo Headphone Output

Mix Routing

1x Main Mix

Meters

Main Meter: 2x 4-Segment LED

Signal Processing

EQ

3-Band EQ

EQ Parameters

Mono Channels:
High: ±12 dB at 12 kHz
Mid: ±12 dB at 2.5 kHz
Low: ±12 dB at 80 Hz

Solo / Mute

No

Built-In Effects

Delay
Chorus
Reverb

Connectivity

Analog Inputs

2x Combo XLR-1/4" Mic/Line Input
4x 1/4" Line Input
1x Stereo RCA Line Input

Analog Outputs

2x XLR 3-Pin Main Output (1 Stereo Pair)
1x 1/4" Aux Output
1x 1/4" TRS Headphone Output

Phantom Power

+48 V

Digital I/O

No

MIDI I/O

No

USB I/O

1x USB-B
USB I/O Capacity: 2x Input / 2x Output

Wireless

No

Compatibility

OS Compatibility

Windows / macOS

Power

DC Input Power

18 VDC at 1.3A

Power Supply Output

Included

Physical

Rack Mountable

No

Packaging Info

Package Weight

3.33 lb

Box Dimensions (L × W × H)

12.2 x 11 x 3.6"
