Key Specifications

Product / Accessory Type

120-Watt Multi-Purpose / Keyboard & Acoustic Combo Amplifier

Acoustic & Electrical Performance Specifications

Amplifier Rated Output Power

120 W Continuous RMS Output

Frequency Response

45 Hz to 20,000 Hz (20.00 kHz, -3 dB)

Equalization Controls (EQ)

Bass Control: ±10 dB (20 Hz to 360 Hz);
Mid Control: ±10 dB (360 Hz to 4,000 Hz);
Treble Control: ±10 dB (4,000 Hz to 20,000 Hz)

Speaker Component Specifications

Low-Frequency Transducers (Woofer)

1x 304.80 mm (12.00") Woofer

High-Frequency Transducers (Tweeter)

2x 50.80 mm (2.00") Tweeters

Connectivity & Impedance Specifications

Input 1 Interface & Impedance

Stereo Input 1 (10 kΩ Impedance)

Input 2 Interface & Impedance

Stereo Input 2 (10 kΩ Impedance)

Auxiliary Input & Impedance

Stereo AUX Input (10 kΩ Impedance)

Direct Output (DI Out) & Impedance

Balanced Differential Line Output / DI Out (560 Ω Impedance)

Power & Electrical Specifications

Operating AC Mains Voltage

100 V to 240 V AC, 50 / 60 Hz Universal Power Supply

Dimensions & Weight Specifications

Product Dimensions (L×W×H)

463.00 mm x 434.00 mm x 405.00 mm (18.23" x 17.09" x 15.94")

Product Net Weight

15.80 kg (34.83 lbs)
