Key Specifications

Microphone Type

Large Diaphragm

Polar Pattern

Cardioid / Figure-8 / Omnidirectional

Element Type

Condenser

Sound Field

Mono

Diaphragm

1" / 25.4 mm

Orientation

Side Address

Controls

Polar Pattern, Pad, Low Cut/HPF

Pad

-10 dB

Filter & EQ

Low-Cut Filter: 20 Hz, 3 dB/Octave / 150 Hz, 3 dB/Octave

Circuitry

Solid-State (JFET)

Performance

Frequency Response

20 Hz to 20 kHz

Maximum SPL

147 dB (1 kHz, 0.5% THD, 1-Kilohm Load)

157 dB (1 kHz, 0.5% THD, 1-Kilohm Load, with Pad)

Sensitivity

-36 dBV/Pa (at 1 kHz)

Dynamic Range

140 dB

Equivalent Noise Level

7 dB (A-Weighted)

Connectivity

Analog Output

1 × XLR 3-Pin Male

Power

Power Sources

Phantom Power

Operating Voltage

24 V / 48 V (Phantom Power)

Physical

Color

Silver

Dimensions

ø: 2.2 × L: 8.2" / ø: 55 × L: 208 mm

Weight

1.8 lb / 831 g

Packaging Information

Package Weight

6.05 lb

Box Dimensions (L × W × H)

16 × 13 × 6.4"
