Key Specifications

Microphone Type

Small Diaphragm

Polar Pattern

Cardioid

Element Type

Condenser

Sound Field

Mono

Diaphragm

0.5" / 12.7 mm

Orientation

End Address

Controls

No

Pad

No

Circuitry

Solid-State (JFET)

Performance

Frequency Response

20 Hz to 20 kHz

Maximum SPL

143 dB (1 kHz, 1% THD, 1-Kilohm Load)

Sensitivity

-38 dBV/Pa (at 1 kHz)

Dynamic Range

128 dB

Equivalent Noise Level

16 dB SPL (A-Weighted)

Connectivity

Analog Output

1 × XLR 3-Pin Male

Power

Power Sources

Phantom Power

Operating Voltage

24 to 48 V (Phantom Power)

Physical

Color

Nickel

Mounting Thread Size

5/8"-27 Female (3/8"-16 Female with Included Adapter)

Dimensions

ø: 0.79 × L: 4.65" / ø: 20 × L: 118 mm

Weight

0.2 lb / 101 g

Packaging Information

Package Weight

1.25 lb

Box Dimensions (L × W × H)

5.5 × 4.78 × 3.2"
