Key Specifications

Acoustic Principle

Pressure Gradient

Active Electronics

JFET impedance converter with bipolar output buffer

Capsule

0.50"

Polar Pattern

Cardioid / Omnidirectional

Address Type

End Address

Performance

Frequency Range

20 Hz to 20 kHz

Maximum SPL

136 dB SPL (1 kHz, 1% THD into 1 kΩ Load)

Maximum Output Level

8.0 dBu (1 kHz, 1% THD into 1 kΩ Load)

Sensitivity

-38.0 dB re 1 V/Pa (12.60 mV @ 94 dB SPL) ±2 dB at 1 kHz

Output Impedance

100 Ω

Connectivity

Output

XLR Output

Power

Power Options

+48 V Phantom Power

Physical

Dimensions

145 × 20 × 20 mm (H × W × D)

Weight

110 g
