NTG4+
NTG4+
RODE
UNIT: PIECE/S
Product Code: SKU:RODE-NTG4+-CHN-336
Key Features
RODE NTG4+
RODE NTG4+
|
Key Specifications |
|
|
Microphone Type |
Shotgun |
|
Polar Pattern |
Supercardioid |
|
Element Type |
Condenser |
|
Sound Field |
Mono |
|
Diaphragm |
0.5" / 12.7 mm |
|
Orientation |
End Address |
|
Controls |
High Boost, On/Off, Pad, Low Cut / HPF |
|
Pad |
-10 dB |
|
Filter & EQ |
Low-Cut Filter: 75 Hz High Boost: +6 dB |
|
Circuitry |
Solid-State |
|
Performance |
|
|
Frequency Response |
20 Hz to 20 kHz |
|
Maximum SPL |
135 dB |
|
Off-Axis Rejection |
5 dB at 60° 24 dB at 120° 18 dB at 180° |
|
Sensitivity |
-32 dBV/Pa (at 1 kHz) |
|
Dynamic Range |
119 dB |
|
Equivalent Noise Level |
16 dB (A-Weighted) |
|
Connectivity |
|
|
Analog Output |
1 × XLR 3-Pin |
|
Power |
|
|
Power Sources |
Phantom Power |
|
Operating Voltage |
48 V |
|
Battery Type |
1 × Built-In Rechargeable (Included) |
|
Physical |
|
|
Color |
Black |
|
Mounting Thread Size |
5/8"-27 Female (3/8"-16 Female with Included Adapter) |
|
Dimensions |
ø: 0.87 × L: 10.94" / ø: 22 × L: 278 mm |
|
Weight |
6.21 oz / 176 g (Microphone) |
|
Packaging Information |
|
|
Package Weight |
1.36 lb |
|
Box Dimensions (L × W × H) |
13 × 5.15 × 2.6" |
