Key Specifications

Speaker Type / Application

TYPE B (Outdoor Applications)

Enclosure Material & Finish

ABS+PC Enclosure (Black / White finish)

Grille & Hardware

Surface-treated Mesh Speaker Grille, Surface-treated Steel Wall Bracket, Joint Bracket, Screws, and Stainless Steel Cable

Acoustic & Transducer Specifications

Transducer (Low)

8" Ferrite Woofer (1.2" Voice Coil, 8 Ω / 80 W)

Transducer (High)

1.0" Neodymium Tweeter Voice Coil

Frequency Response

50 Hz to 20 kHz

Sensitivity

87 dB (1W/1m) [500Hz-5kHz, Pink Noise]
76 dB (1W/4m) [100Hz-10kHz, Pink Noise, EN54-24 standard]
87 dB (1W/1m) [100Hz-10kHz, Pink Noise, EN54-24 converted]

Maximum Sound Pressure Level (SPL)

87 dB (80W/4m) [100Hz-10kHz, Pink Noise, EN54-24 standard]
105 dB (80W/1m) [100Hz-10kHz, Pink Noise, EN54-24 converted]

Coverage Angle (-6dB)

Horizontal: 215° (500Hz), 130° (1kHz), 135° (2kHz), 165° (4kHz)
Vertical: 360° (500Hz), 235° (1kHz), 100° (2kHz), 180° (4kHz)

Electrical & Transformer Specifications

Rated Noise Power & Line Voltage

80 W (100V line and 70V line)

100V Line Tapped Impedances

1000 Ω, 500 Ω, 250 Ω, 125 Ω (Bypass)

70V Line Tapped Impedances

500 Ω, 250 Ω, 125 Ω, 62 Ω (Bypass)

Direct / Bypass Impedance

8 Ω

Cable & Connection Specs

Steatite Terminal x2 | Cable Diameter: 6 mm [White(+), Black(COM)]
Applicable Cable: Solid Wire ø6.0 mm (18 AWG) UL2464

Environmental & Physical Specifications

Enclosure Protection Degree (IP)

IP55 / IP33C (EN54-24)

Operating Temperature Range

-25°C to +70°C

Item Dimensions (H×W×D)

250mm x 406mm x 251mm (9.8" x 16.0" x 10.0")

Item Weight

6.3 kg (13.9 lbs)
