Key Specifications

Control Surface

Bank Navigation

Up/Down Buttons with Numerical Display

Main Go Section

Snap, Release, Pause, and Go Buttons

Command Buttons

Record, Edit, Update, Load, Clear

Mode Control

Multifunction Mode Select Button

Fixture Selection

Last, Next, Highlight Buttons

Parameter Select Buttons

4

Parameter Adjust Faders

4 Touch Faders

Function Pads

10 Velocity Pads

Playback Faders

10 Touch Faders with 3 Buttons Each (2 Touch Pads, 1 Velocity Pad)

Connections

DMX Output

1x 5-Pin Locking XLR

USB Input

USB-B 2.0

System Requirements

Operating System

Windows 10 / Windows 11 64-Bit (Home, Pro, Enterprise)

Processor

Intel Core i3 6th Generation or Higher (or Comparable Multi-Core Processor)

Memory

8 GB RAM

Storage

SSD Drive Required

Available Disk Space

40 GB

Display Requirement

Widescreen Monitor, Minimum 1280 × 768 Resolution (Capacitive Multi-Touch Recommended)

USB Port

USB 2.0

Art-Net Network Port

10/100 Ethernet Port

X-Net / Remote / sACN Network Port

100/1000 Ethernet Port

Physical

Length

394 mm (15.5 in.)

Width

218.5 mm (8.6 in.)

Height

46.5 mm (1.8 in.)

Weight

1.5 kg (3.3 lb)
