Key Specifications

Speaker Type

Active Column Array

Configuration

2-Way

Enclosure Type

Bass-Reflex

Total Output Power

2100 W Peak

Frequency Range / Response

45 Hz to 20 kHz

Maximum SPL

135 dB

Coverage Angle

100° Horizontal × 50° Vertical

Drivers

Low Frequency Driver

3 × 10" / 25.4 cm Woofer
Voice Coil: 2.5" / 63.5 mm
Magnet: Neodymium

High Frequency Driver

1 × 1.4" / 35.6 mm Horn-Loaded Titanium Dome Compression Driver
Voice Coil: 3" / 7.6 cm

Amplifier Power Rating

Low Frequency (LF)

1400 W Peak

Mid Frequency (MF)

700 W Peak

Amplifier Class

Class-D

Signal Processing

Crossover Frequency

800 Hz

EQ & Filters

High-Pass Filter

Dynamic Processing

Soft Limiter

Alignment Delay

No

Digital Signal Processing

User Settings

Protections

Excursion, RMS, Thermal

Connectivity

Audio I/O

1 × Combo XLR-1/4" TRS Line Input
1 × XLR 3-Pin Line Output

Network I/O

No

USB I/O

No

Wireless

No

Mobile App Compatible

No

Power

AC Input Power

100 to 120 VAC, 60 Hz

AC Power I/O

1 × powerCON TRUE1 Input
1 × powerCON TRUE1 Output

Physical

Color

Black

Mounting

Stand Mount
1 × Pole Socket (Bottom, Size Unspecified)
Suspension Points
8 × M8 Fly Points
8 × Integrated Rigging

Handles

1 × Each Side

Construction Material

Plywood, Stainless Steel Grille

Dimensions (W × H × D)

45.5 × 14.7 × 11.7" / 115.6 × 37.3 × 29.7 cm

Weight

69.5 lb / 31.5 kg
