Key Specifications

Waterproof

20 m without the Waterproof Case, 60 m with the Waterproof Case

Before use, close the battery compartment cover and the USB-C port cover, and tighten the Glass Lens Cover. It is recommended to install Waterproof Case for long-term underwater shooting or in environments with high water impact pressure. Osmo Action 6 and its Waterproof Case have an IP68 waterproof rating. Do not use the camera in hot springs or extreme underwater environments, or let it come into contact with corrosive or unknown liquids.

Number of Microphones

3

Touchscreens

Front Screen: 1.46-inch 331 ppi 342×342
800 cd/㎡ max brightness (typical)

Rear Screen: 2.5-inch 326 ppi 400×712
800 cd/㎡ max brightness (typical), 1000 cd/㎡ peak brightness

Supported SD Cards

microSD (up to 1 TB)

Recommended microSD Cards

Recommended Models:

Lexar Professional SILVER PLUS 64GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 128GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 256GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 512GB U3 A2 V30 microSDXC
Lexar Professional SILVER PLUS 1TB U3 A2 V30 microSDXC

Kingston CANVAS Go! Plus 64GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 128GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 256GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 512GB U3 A2 V30 microSDXC
Kingston CANVAS Go! Plus 1TB U3 A2 V30 microSDXC

Camera

Sensor

1/1.1-inch CMOS

Lens

FOV: 155°
Aperture: f/2.0-f/4.0
Focus Range (at aperture f/4.0): 0.2 m to ∞

ISO Range

Photo: 100-25600
Video: 100-51200*

* ISO 51200 is available only in SuperNight mode. For all other video modes, the maximum ISO is 25600.

Electronic Shutter Speed

Photo: 1/8000-30 s
Video: 1/8000s to the limit of frames per second

Max Photo Resolution

7168×5376

Zoom

Digital Zoom
Photo: Max 2×
Video: Max 2×

Not supported in 38MP/34MP photo mode, SuperNight, Subject Tracking, Slow Motion, or Timelapse modes.

Still Photography Modes

Single: Approx. 38 MP
Countdown: Off/0.5/1/2/3/5/10 s
Burst: Up to 30 images/3 s

Video

8K (16:9): 7680×4320@24/25/30fps*
4K Custom: 3840×3840@24/25/30/48/50/60fps
4K (4:3): 3840×2880@100/120fps
4K (4:3): 3840×2880@24/25/30/48/50/60fps
4K (16:9): 3840×2160@100/120fps
4K (16:9): 3840×2160@24/25/30/48/50/60fps
4K (9:16): 2160×3840@100/120fps
4K (9:16): 2160×3840@24/25/30/48/50/60fps
2.7K (4:3): 2688×2016@100/120fps
2.7K (4:3): 2688×2016@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@100/120fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@100/120fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@100/120/200/240fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@100/120/200/240fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps

* 8K recording is restricted to 16:9 aspect ratio. EIS is limited to RockSteady/RockSteady+, and FOV options to Standard, Natural Wide, and Wide. Film Tone and Quality Priority are unavailable. Max ISO: 12800 (normal color) or 6400 (D-Log M). Downloading and editing 8K footage in DJI Mimo app is currently supported only on iPhone 15 Pro series and later models, and support for other devices is subject to future app updates.

SuperNight

4K (16:9): 3840×2160@24/25/30/48/50/60fps
2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps

Subject Tracking

2.7K (16:9): 2688×1512@24/25/30/48/50/60fps
2.7K (9:16): 1512×2688@24/25/30/48/50/60fps
1080p (16:9): 1920×1080@24/25/30/48/50/60fps
1080p (9:16): 1080×1920@24/25/30/48/50/60fps

Slow Motion

4K: 4x (120fps)
2.7K: 4x (120fps)
1080p: 8x (240fps), 4x (120fps)

Hyperlapse

4K/2.7K/1080p@25/30fps: Auto/×2/×5/×10/×15/×30

Timelapse

4K/2.7K/1080p@25/30fps
Intervals: 0.5/1/2/3/4/5/6/8/10/15/20/25/30/40 s, 1/2/5/30/60 mins
Duration: 5/10/20/30 mins, 1/2/3/5 hours, ∞

Stabilization

EIS:
RockSteady 3.0
RockSteady 3.0+
HorizonBalancing
HorizonSteady

EIS is not supported in Slow Motion and Timelapse modes. HorizonSteady and HorizonBalancing are supported for 1080p (16:9), 2.7K (16:9), 4K (16:9), and 4K Custom videos with frame rates of 60fps or below.

Pre-Rec

Pre-Recording Duration: 5/10/15/30 s, 1/2/5 mins

Max Video Bitrate

120 Mbps

Supported File System

exFAT

Photo Format

JPEG/RAW

Video Format

MP4 (HEVC)

Built-in Storage Capacity

The camera features 64 GB of built-in storage, with 50 GB available for use. The storage capacity can be expanded by inserting a microSD card.

Audio Recording

48 kHz 16-bit; AAC

Battery

Type

Li-ion 1S

Capacity

1950 mAh

Energy

7.5 Wh

Voltage

3.87 V

Operating Temperature

-20° to 45° C (-4° to 113° F)

Charging Temperature

5° to 40° C (41° to 104° F)

Operating Time

240 minutes

Measured at a room temperature of 25° C (77° F), while recording 1080p/24fps (16:9) video, with RockSteady on, Wi-Fi off, Voice Control and Gesture Control off, and screens off. Data was collected in a controlled environment and should be taken as reference only.

Connection

Wi-Fi Operating Frequency

2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz

Wi-Fi Protocol

Wi-Fi 6.0
802.11 a/b/g/n/ac/ax

Wi-Fi Transmitter Power (EIRP)

2.4 GHz: < 23 dBm (FCC), < 20 dBm (CE/SRRC/MIC)
5.1 GHz: < 23 dBm (FCC/CE/SRRC/MIC)
5.8 GHz: < 23 dBm (FCC/SRRC), < 14 dBm (CE)

Bluetooth Operating Frequency

2.400-2.4835 GHz

Bluetooth Transmitter Power (EIRP)

< 13 dBm

Bluetooth Protocol

BLE 5.1

Dimensions

72.8×47.2×33.1 mm (L×W×H)

Weight

149 g
