Key Specifications

Family

Prestige Series

Line Voltage

240 Volts

Maximum Output Current

6 A @ 230 V (230 V output setting)
6 A @ 240 V (240 V output setting)

Line Cord

Detachable 2.5 m black cord with Schuko plug (standard)

BNC Socket with Switch

For rear rack lamp: 12 VAC, 500 mA max (lamp not included)

In Regulation Range

182–262 VAC (230 V output setting)
188–270 VAC (240 V output setting)

Over Voltage Shutdown

275 VAC nominal

Spike Protection Modes

Line to Neutral, Zero Ground Leakage

Spike Clamping Voltage

376 VAC peak @ 3,000 A

Response Time

1 nanosecond

Maximum Surge Current

6,500 A

Noise Attenuation

10 dB @ 10 kHz, 40 dB @ 100 kHz, 50 dB @ 500 kHz

Dimensions (W × D × H)

19 × 12.0 × 1.745" (482.6 × 304.8 × 44.3 mm)

Weight

9.5 kg

Power Consumption

5 W (No load)

UPC

654061028154
