Key Specifications

Size & Weight

Dimensions

Width: 1,326 mm [52-3/16"]
Height: 129 mm [5-1/16"] (with music rest: 327 mm [12-7/8"])
Depth: 272 mm [10-11/16"] (with music rest: 362 mm [14-1/4"])

Weight

11.5 kg [25 lb, 6 oz]

Dimensions (with optional stand)

Width: 1,326 mm [52-3/16"]
Height: 744 mm [29-5/16"] (with music rest: 942 mm [37-1/16"])
Depth: 318 mm [12-1/2"] (with music rest: 362 mm [14-1/4"])

Packing Box Dimensions

1,424 mm × 362 mm × 233 mm [56-1/16" × 14-1/4" × 9-3/16"]

Control Interface

Keyboard

88 keys
GHC keyboard with matte black keytops

Touch Sensitivity

Hard / Medium / Soft / Fixed

Panel Language

English

Voices & Tone Generation

Piano Sound

Yamaha CFX

Key-off Samples

Yes

Virtual Resonance Modeling (VRM)

Yes (VRM Lite)

Damper Resonance

-

Maximum Polyphony

192

Number of Voices

24

Effects

Reverb

4 types

Wall EQ

Yes

Intelligent Acoustic Control (IAC)

Yes

Stereophonic Optimizer

Yes

Sound Boost

2 types

Performance Functions

Dual/Layers

Yes

Split

Yes

Duo

Yes

Songs & Recording

Preset Songs

21 Voice Demo Songs + 50 Classics

MIDI Recording

1 song
2 tracks
Approx. 100 KB/song (approx. 11,000 notes)

Functions

Metronome

Yes

Tempo Range

5 – 280

Transpose

−6 – 0 – +6

Tuning

414.8 – 440.0 – 466.8 Hz (approx. 0.2 Hz increments)

USB Audio Interface

44.1 kHz, 24-bit, stereo

Rhythms

20

Bluetooth

Audio (varies by country)

Storage & Connectivity

Headphones

Standard stereo phone jack ×2

AUX OUT

[L/L+R] [R]

USB TO HOST

Yes

DC IN

12 V

Sustain Pedal

Yes

Pedal Unit

Yes

Amplifiers & Speakers

Amplifiers

7 W × 2

Speakers

(Oval 12 cm × 8 cm + 5 cm) × 2

Power

AC Adaptor

PA-150B or equivalent recommended by Yamaha (DC 12 V, 1.5 A)

Power Consumption

9 W

Accessories

Included Accessories

Owner’s Manual, Online Member Product Registration, Music rest, Footswitch, AC adaptor (PA-150B or equivalent)

Optional Accessories

HPH-150 / HPH-100 / HPH-50 headphones, L-200 keyboard stand, LP-1 pedal unit, FC3A foot pedal, FC4A / FC5 footswitches, SC-KB851 keyboard bag, PA-150B AC adaptor, UD-BT01 wireless MIDI adaptor
