Key Specifications

Power & Performance

Power Source

220 - 240 V AC, 50/60 Hz

Rated Output

480 W

Power Consumption

601 W (Rated) / 113 W (EN62368)

Frequency Response

50 Hz to 20 kHz ±3 dB

S/N Ratio

≥ 90 dB (Master Min) / ≥ 76 dB (Master Max)

Audio Connectivity

Line Input

0 dB / -20 dB (Switchable), Transformer Balanced

Speaker Line In

40 dB (100 V Line), 65 kΩ, Balanced

Speaker Output

Low (4-16 Ω) / High (21 Ω / 100 V)

Line Output

0 dB, 600 Ω, Unbalanced RCA × 2

Control & Monitoring

Control I/O

Power Remote (In/Out), Emergency (In/Out)

Indicators

5-point LED Meter, Power, Emergency, Protection

Tone Control

Bass: ±10 dB (100 Hz), Treble: ±10 dB (10 kHz)

Physical Specifications

Dimensions (W x H x D)

420 × 96.1 × 313.1 mm (16.54 × 3.78 × 12.33")

Weight

5 kg (11.02 lb)

Finish

Black ABS Panel, Steel Plate Case
