Key Specifications

Size & Weight

Dimensions (W × H × D)

1,329 × 167 × 410 mm (52-5/16" × 6-9/16" × 16-1/8")

Weight

21.8 kg (48 lb, 1 oz)

Packing Box Dimensions

1,457 × 311 × 531 mm (57-3/8" × 12-1/4" × 20-7/8")

Keyboard

Number of Keys

88

Keyboard Type

GHS (Graded Hammer Standard) keyboard with matte black keytops

Touch Sensitivity

Hard2, Hard1, Medium, Soft1, Soft2, Fixed

Display & Panel

Display Type

Full Dot LCD

Display Size

80 × 16 dots

Display Language

English, Japanese

Score Display Function

Yes (*)

Lyrics Display Function

Yes (*)

Panel Type

Touch Sensors

Panel Language

English

Voices & Tone Generation

Piano Sound

Yamaha CFX, Bösendorfer Imperial

Binaural Sampling

Yes (“CFX Grand” only)

Virtual Resonance Modeling (VRM)

Yes

Key-off Samples

Yes

Max Polyphony

256

Number of Voices

660 (100 when not connected to Smart Pianist)

Featured Voices

13 VRM Voices
111 Super Articulation Voices
25 Natural! Voices
27 Sweet! Voices
47 Cool! Voices
58 Live! Voices
29 Organ Flutes! Voices

Compatibility

XG, GS, GM, GM2

Effects

Reverb

58 types (5 types when not connected to Smart Pianist)

Master EQ

5 Presets + User (*)

Intelligent Acoustic Control (IAC)

Yes

Stereophonic Optimizer

Yes

Vocal Harmony

44 Presets (*)

Functions

Dual / Layers

Yes (*)

Split

Yes (*)

Piano Room

Yes (*)

Metronome

Yes

Tempo Range

5 – 500, Tap Tempo

Transpose

-12 – 0 – +12

Tuning

414.8 – 440.0 – 466.8 Hz

Scale Type

9 (*)

Accompaniment Styles

Preset Styles

370 (100 when not connected to Smart Pianist)

Featured Styles

328 Pro Styles, 25 Session Styles, 3 Free Play Styles, 13 Pianist Styles

Style Control

INTRO ×1, ENDING ×1, MAIN ×4

Songs & Recording

Preset Songs

403 (100 when not connected to Smart Pianist)

Recording Tracks

16 (*)

Recording Function

Yes (*)

Playback Format

SMF (Format 0 & 1), XF

Recording Format

SMF (Format 0)

Lesson / Guide

Correct Key, Any Key (*), Your Tempo (*)

Guide Lamp

Stream Lights (4 steps)

USB Audio

USB Audio Recorder

Playback supported by Smart Device / Recording in WAV & AAC

Time Stretch

Yes (*)

Pitch Shift

Yes (*)

Vocal Cancel

Melody Suppressor (*)

Audio to Score

Yes (*)

Registration Memory

Yes (*)

Storage & Connectivity

Headphones

2 × Standard Stereo Phone Jack

Microphone Input

Standard mono phone jack with input volume

AUX IN

Stereo Mini

AUX OUT

Standard Phone Jack (R, L/L+R)

Pedal Support

AUX Pedal, Pedal Unit

USB TO DEVICE

Yes

USB TO HOST

Yes

iPad Power Supply

5 V, 2.1 A

DC IN

24 V

Amplifiers & Speakers

Amplifiers

(20 W + 6 W) × 2

Speakers

(Oval 12 cm × 6 cm + 2.5 cm dome) × 2

Power

Power Supply

PA-500

Power Consumption

40 W (using PA-500 AC adaptor)

Auto Power Off

Yes

Accessories

Included Accessories

Owner’s Manual
Online Member Product Registration
AC Adaptor PA-500 (may vary by region)
Music Rest
Footswitch
USB Cable (USB Type A – USB Type B)
USB Conversion Cable (USB Type A – USB Micro B / USB Type A – USB Type C)

Notes

Additional Note

(*) Features available when connected to Smart Pianist
