Key Specifications

Acoustical

Frequency Response

80 Hz to 20 kHz

Maximum SPL

121 dB @ 1 m

Coverage Angle

Horizontal: 90°
Vertical: 60°

Directivity

Index, Q: 11

Sensitivity

95 dB

Impedance

16 Ω

Power Handling

100 W

Peak Power Output

400 W

Recommended Amplifier Power

200 W

Protection

Dynamic Protection on Compression Driver

Crossover Frequencies

2200 Hz

Transducers

Driver

1.0" (25.4 mm) Throat, 1.5" (38.1 mm) Coil Diaphragm Assembly

Woofer

8.0" (203.2 mm) Woofer, 1.5" (38.1 mm) Voice Coil

Impedance

Compression Driver: 8 Ω
Woofer: 16 Ω

Input Power

Compression Driver: 20 W AES
Woofer: 100 W AES

Sensitivity

Compression Driver: 107 dB
Woofer: 94 dB

Input

Input Connector

4 x 0.05" (1.5 mm) Square, 6.56' (2 m) Neoprene Cable

Voltage

Constant Voltage Transformer: 70/100 V

Power Selection

70 V: 30 W, 15 W
100 V: 60 W, 30 W

Cabinet / Accessories

Material

0.31" (8 mm) Polyethylene Roto-Molded

Grille

Custom Perforated Aluminum Grille with Open-Cell Fiber and Water Repellent Woven Fabric Backing

Dimensions

10.47 x 19.4 x 9.84" / 266 x 493 x 250 mm

Weight

27.55 lb / 12.5 kg
