Key Specifications

Frequency Response (-10 dB)

95 Hz to 20 kHz

Maximum SPL @ 1 m

124 dB

Horizontal Coverage Angle

90°

Vertical Coverage Angle

40°

Directivity Index (Q)

11

System Sensitivity

95 dB

Power Section

Amplification

Full Range

Nominal Impedance

16 Ω

Power Handling

200 W

Peak Power Handling

800 W Peak

Protections

Dynamic active MOSFET

Crossover Frequency

2000 Hz

Transducers

Compression Driver

1.0" diaphragm, 1.5" voice coil

Woofer

Coaxial 10", 2.5" voice coil

Input / Output Section

Input Connector

Neoprene Cable

Constant Voltage Transformer

100 V

Power Selection 1

60 W – 167 Ω

Power Selection 2

30 W – 333 Ω

Power Selection 3

15 W – 667 Ω

Standard Compliance

IP Protection Grade

IP55

Safety Agency

CE Compliant

Physical Specifications

Cabinet / Case Material

PE Low Density

Hardware

12 x M8 inserts + U-brackets and pair of spacers

Grille

Aluminum with water-repellent protection

Color

Grey (RAL 7011)

Size / Weight

Height

350 mm / 13.78"

Width

350 mm / 13.78"

Depth

320 mm / 12.6"

Weight

13.4 kg / 29.54 lb

Shipping Information

Package Height

400 mm / 15.75"

Package Width

370 mm / 14.57"

Package Depth

370 mm / 14.57"

Package Weight

16.3 kg / 35.94 lb
