Key Specifications

Frequency Response

80 Hz to 20 kHz

Maximum SPL

@ 1 m: 125 dB

Coverage Angle

Horizontal: 90°
Vertical: 60°

Directivity

Index (Q): 11

Sensitivity

94 dB

Impedance

8 Ω

Power Handling

300 W

Peak Power Output

1200 W

Protection

Dynamic

Crossover Frequency

1800 Hz

Transducers

High-Frequency Driver

1.0" (25.4 mm) HF driver, 2.5" (63.5 mm) voice coil

Woofer

8.0" (203.2 mm) woofer, 2.5" (63.5 mm) voice coil

Impedance

Compression Driver: 8 Ω
Woofer: 8 Ω

Input Power

Compression Driver: 25 W AES
Woofer: 300 W AES

Sensitivity

Compression Driver: 109 dB
Woofer: 95 dB

Cabinet / Accessories

Material

Polyethylene roto-molded

Grille

Custom perforated aluminum grille with open-cell fiber and water-repellent woven fabric backing

Dimensions (W × H × D)

10.47 x 19.41 x 9.84" / 266 x 493 x 250 mm

Weight

22 lb / 10 kg

Packaging Info

Package Weight

25.25 lb

Box Dimensions (L × W × H)

21 x 11.2 x 11"
