Key Specifications

Frequency Response (-10 dB)

75 Hz - 20 kHz

Maximum SPL @ 1 m

129 dB

Coverage Angle

Horizontal: 90°
Vertical: 60°

Directivity Index (Q)

13

System Sensitivity

98 dB

Power Section

Amplification

Full Range

Nominal Impedance

16 Ω

Power Handling

300 W

Peak Power Handling

1200 W PEAK

Protections

Dynamic active MOSFET

Crossover Frequency

1300 Hz

Transducers

Compression Driver

1.0" / 25.4 mm, 1.5" voice coil

Woofer

Coaxial 15", 2.5" voice coil

Input / Output Section

Input Connector

Neoprene Cable

Constant Voltage Transformer

100 V

Power Selection 1

120 W - 83 Ω

Power Selection 2

60 W - 167 Ω

Power Selection 3

30 W - 333 Ω

Standard Compliance

IP Protection Grade

IP 55

Safety Agency

CE compliant

Physical Specifications

Cabinet / Case Material

PE Low Density

Hardware

12 x M10 inserts + U-brackets and pair of spacers

Grille

Aluminum with water-repellent protection

Color

Grey - RAL 7011, White - RAL 9003

Dimensions (H × W × D)

463 x 463 x 433 mm / 18.23 x 18.23 x 17.05 inches

Weight

18.4 kg / 40.57 lbs

Shipping Information

Package Height

530 mm / 20.87 inches

Package Width

490 mm / 19.29 inches

Package Depth

490 mm / 19.29 inches

Package Weight

23.2 kg / 51.15 lbs
