Key Specifications

System Performance

RF Frequency Band

H20: 518 to 542 MHz

Transmission Range

300' / 90 m (Line of Sight)

Audio Frequency Response

38 Hz to 15 kHz

Transmitter (P3T)

RF Output Power

Selectable: 10, 20, 30 mW (Region dependent)

Audio Inputs

2x 1/4" TRS Balanced (+4 dBu / -10 dBV switchable)

Audio Outputs

2x 1/4" TRS Balanced (Loop Out)

Dimensions / Weight

198 x 172 x 43 mm / 783 g (27.6 oz)

Bodypack Receiver (P3R)

Audio Output Power

80 mW per output (1 kHz @ <1% distortion)

Headphone Jack

1/8" (3.5 mm) Stereo

Battery Life

5–7 Hours (AA Alkaline)

Weight

98 g (3.5 oz) without batteries

Earphones (SE112)

Driver Type

Single Dynamic MicroDriver

Sensitivity / Impedance

105 dB SPL/mW / 16 Ohms

Noise Isolation

Up to 37 dB (Passive)
