Key Specifications

Frequency Response (-10 dB)

80 Hz - 20 kHz

Maximum SPL @ 1 m

129 dB

Coverage Angle

Horizontal: 110°
Vertical: 60°

Directivity Index (Q)

9

System Sensitivity

97 dB

Power Section

Amplification

Full Range

Nominal Impedance

8 Ω

Power Handling

400 W

Peak Power Handling

1600 W PEAK

Protections

Dynamic active MOSFET

Crossover Frequency

1100 Hz

Transducers

Compression Driver

1 x 1.4" neo, 2.5" voice coil

Woofer

2 x 8", 2.5" voice coil

Input / Output Section

Input Connector

Amphenol eco/mat IP 67

Standard Compliance

IP Protection Grade

IP 55

Safety Agency

CE compliant

Physical Specifications

Cabinet / Case Material

PE Low Density

Hardware

4 x M8 + U-bracket and pair of spacers

Grille

Aluminum with water-repellent protection

Color

Grey - RAL 7011, Black - RAL 9005, White - RAL 9003

Dimensions (H × W × D)

268 x 566 x 250 mm / 10.55 x 22.28 x 9.84 inches

Weight

14 kg / 30.86 lbs

Shipping Information

Package Height

290 mm / 11.42 inches

Package Width

590 mm / 23.23 inches

Package Depth

290 mm / 11.42 inches

Package Weight

15.6 kg / 34.39 lbs
