Key Specifications

Frequency Response (-10 dB)

75 Hz - 20 kHz

Maximum SPL @ 1 m

134 dB

Coverage Angle

Horizontal: 60°
Vertical: 60°

Directivity Index (Q)

13

System Sensitivity

100 dB

Power Section

Amplification

Full Range

Nominal Impedance

8 Ω

Power Handling

600 W

Peak Power Handling

2400 W PEAK

Protections

Dynamic active MOSFET

Crossover Frequency

1100 Hz

Transducers

Compression Driver

1.3" neo, 2.5" voice coil

Woofer

Coaxial 15" neo, 3.0" voice coil

Input / Output Section

Input Connector

Neoprene Cable

Standard Compliance

IP Protection Grade

IP 55

Safety Agency

CE compliant

Physical Specifications

Cabinet / Case Material

PE Low Density

Hardware

12 x M10 + U-Bracket and Pair of Spacers

Grille

Aluminum with water-repellent protection

Color

Grey - RAL 7011, White - RAL 9003

Dimensions (H × W × D)

463 x 463 x 433 mm / 18.23 x 18.23 x 17.05 inches

Weight

17 kg / 37.48 lbs

Shipping Information

Package Height

519 mm / 20.43 inches

Package Width

489 mm / 19.25 inches

Package Depth

489 mm / 19.25 inches

Package Weight

21.4 kg / 47.18 lbs
