Key Specifications

RF Performance

Frequency Band

K1E: 596 – 632 MHz

RF Sensitivity

2.2 μV (at 20 dB SINAD)

Image / Adjacent Channel Rejection

>90 dB / >70 dB

Intermodulation / Blocking

>70 dB / >80 dB

Audio & DSP Features

Output Power

100 mW per output (at 16 Ohms)

On-Board EQ

4-Band Parametric (Low, Low-Mid, High-Mid, High)

Volume Limiter / Lock

Selectable 0 to -48 dB / Selectable 0 to -70 dB

Audio Connector

1/8" (3.5 mm) TRS Stereo

Power & Physical

Battery Life

4–6 Hours (Continuous use with 2x AA)

Housing

Rugged Metal Construction

Dimensions / Weight

8.3 x 6.5 x 2.2 cm / 154 g (without batteries)
