Key Specifications

System Type

Wall Mount Speaker

Drivers

1" Tweeter
5" Woofer

Power Rating @ 8Ω (Nominal)

50 W

Rated Noise Power

100h 50 W

Power Rating @ 100V

50 / 25 / 12.5 / 6.25 W

Power Rating @ 70V

50 / 25 / 12.5 / 6.25 / 3.12 W

Impedance

8 Ω (nominal)
200 / 400 / 800 / 1.6K Ω @ 100V
100 / 200 / 400 / 800 / 1.6K Ω @ 70V

Connector

Ceramic Terminal Block

Power Selection

Rotary Switch

Measure Environment

Free Field

Frequency Response (-10 dB)

90 - 20k Hz

Sensitivity at 1W (1 kHz, 1m / 4m)

89.6 / 77.6 dB

Sensitivity at 1W (Pink Noise 6dB Crest Factor, 1m / 4m)

86.6 / 74.6 dB

Max SPL (Pink Noise 6dB Crest Factor, 1m / 4m)

100.4 / 88.4 dB

Coverage Angle at 500 / 1k / 2k / 4k Hz (-6dB)

Hor: 360° / 180° / 130° / 85°
Vert: 360° / 145° / 85° / 35°

Cabinet

Black (RAL 9011) / White (RAL 9016)

Material

ABS / Aluminium

Environmental Type

B (IP55C using PG11 glands)

Operating Temperature

-25 ÷ +70 °C (-13 ÷ +158 °F)

Relative Humidity

<95%

Dimensions (mm)

170 × 245 × 175 (W × H × D)

Mounting

On wall using supplied bracket

Weight

2.3 kg (5.07 lb)

Standard Compliance

EN54-24:2008

Certification

0051-CPR-1996
