Key Specifications

Video

Video Output

2 x HDMI

Display Resolution

Supports up to 4K, Touch Display Compatible

Content Sharing

Apple Airplay (only supported by Zoom)
HDMI input
Microsoft Teams-Cast (only supported by Teams)

Number of Cameras

3

Type of Camera

Panoramic multi-camera array

Camera Resolution

Up to 3840 x 1080 px

Zoom

Up to 6x lossless digital zoom

Field of View

Horizontal: 180°
Vertical: 54°

Intelligent Zoom

Yes

Intelligent Meeting Space

Yes

Multi-stream Dynamic Composition

Yes

Dynamic Composition

Yes

Virtual Director

Yes

Vivid HDR

Yes

Support Secondary External USB Camera

Yes

Audio

Supported Number of SpeakerMics

1

Audio Coverage

Up to 7 m

Audio Coverage (PanaCast 55 VBS with PanaCast SpeakerMic)

Up to 11 m

Speakers

2 x 2" (50mm) woofers
2 x 3/4" (20mm) tweeters

Speaker Frequency Range

80Hz - 20000Hz

Number of Speakers

4

Automatic Speaker Detection

Yes

Noise Reduction Echo Cancellation

Yes

Non-Speech Noise Suppression

Yes

Woofer Driver

2 inches, outer diameter 61mm
Sensitivity: 79dB ±2dB @ 1 Watt, 1 meter
Rated Power: 5 Watts
Impedance: 4 Ohms

Mid-Range Driver

0.6 inches, outer diameter 33.2mm
Sensitivity: 80.5dB ±2dB @ 1 Watt, 1 meter
Rated Power: 5 Watts
Impedance: 4 Ohms

Microphone Type

8 microphone beamforming array - certified for rooms up to 4.5m x 6m

Number of Microphones

8

Microphone Sensitivity

-37dBFS

Microphone Frequency Range

100Hz - 16000Hz

Aux-Out

Yes

Security

Media Encryption

Provided by VaaS Partner

Access Management

Jabra+
Admin menus
Jabra Web Console
Local account
VaaS Admin Portals including MS Teams Admin Centre and Zoom Device Management

Security Management

Remote log in via Jabra+
Jabra Web Console
VaaS Admin Portal

Authenticated Access

Authenticated access to Admin settings, Jabra Web Console, and Jabra+

Secure Boot & Vendor Lock

Lockdown with secureboot, OS verified boot, Vendor lock

Log Retrieval

Via Jabra Web Console

VaaS Account Authentication

Microsoft and Zoom based VaaS account authentication

Connectivity

Interfaces

Ethernet (RJ45)
HDMI
Wi-Fi (802.11a/b/g/n/ac)
1 x USB-A
2 x USB-C

Bluetooth Version

5.1

Supported USB Versions

USB 2.0, USB 3.0

Network

Internet Protocol (IP)

IPv4, IPv6

Ethernet

RJ45

Auto-MDIX

Yes

Proxy Support

HTTPS

Support DHCP

Yes

Support Static IP Address

Yes

Software & Apps

Compatible Software and/or Apps

Jabra+
Jabra Web Console for remote device management via HTTPS
Support for native 3rd party applications including Microsoft Teams Room for Android and Zoom Rooms
Cloud service providers including Microsoft Teams Admin Center and Zoom Device Management

Integrated People Count

Yes

Ease of Use

Appliance Mode

Yes

BYOD Mode

Yes

Digital Pan/Tilt/Zoom

Yes

Manual Pan-Tilt-Zoom (PTZ)

Yes

One Touch Meeting Join

Yes

Camera Privacy Cover

Yes
