Key Specifications

Rated Input

6 W (100 V Line), 3 W (70 V Line)

Rated Impedance

100 V Line: 1.7 kΩ (6 W), 3.3 kΩ (3 W)
(6.7 kΩ (1.5 W), 13 kΩ (0.8 W): Internal wiring must be changed)
70 V Line: 1.7 kΩ (3 W), 3.3 kΩ (1.5 W)
(6.7 kΩ (0.8 W), 13 kΩ (0.4 W): Internal wiring must be changed)

Sound Pressure Level

90 dB (1 W, 1 m, 330 Hz - 3.3 kHz, pink noise)

Frequency Response

100 Hz - 16 kHz

Speaker Component

12 cm dynamic cone-type speaker

Speaker Mounting Method

Spring catch

Applicable Cable

600 V vinyl-insulated cable (IV wire or HIV wire)
Solid copper wire: φ0.8 - φ1.2 mm
7-core twisted copper wire: 0.75 - 1.25 mm²

Connection

Push-in connector (Bridging terminal-2 branch type)

Finish

Baffle: ABS resin, off-white (RAL 9010 or equivalent color)

Dimensions

φ260 × 92 (D) mm (Exposed section)

Weight

820 g (Bracket included)
