Key Specifications

Output Power (1 kHz, Non-Clip, 20 msec Burst, All Channels Driven)

16Ω: 300 W × 4
8Ω: 600 W × 4
4Ω: 900 W × 4
2Ω: 1300 W × 4
8Ω (Bridge Mode): 1800 W × 2
4Ω (Bridge Mode): 2600 W × 2
Hi-Z (70 V Mode): 600 W × 4
Hi-Z (100 V Mode): 600 W × 4

Amplifier Type

Class D, Single-Ended Output

THD+N

8Ω, 1 kHz, 10 W: 0.01%
4Ω, 1 kHz, Half Power: 0.1%

Frequency Response

8Ω, 1 W, 20 Hz–20 kHz (HPF THRU): +0.5 / -1.5 dB

Crosstalk

≤ -60 dB (8Ω, 1 kHz, Half Power, A-Weighted)

Signal-to-Noise Ratio

109 dB (8Ω, Gain = 32 dB, A-Weighted)

Maximum Input Voltage

+28 dBu

Input Impedance

20 kΩ (Balanced)

Dante Interface

Channel Count

16 IN (with Redundancy), 16 OUT

Sampling Frequency

96 / 88.2 / 48 / 44.1 kHz

Power

AC Power Requirements

100–240 V, 50/60 Hz

Power Consumption

1100 W (1/8 Max Power, 2Ω, Pink Noise)
190 W (Idle)
Standby: 9 W (120 V), 12 W (230 V)

Environmental

Operating Temperature

0°C–40°C (32°F–104°F)

Storage Temperature

-20°C–60°C (-4°F–140°F)

Physical

Dimensions (W × H × D)

480 × 88 × 528 mm
18.9 × 3.5 × 20.8 in

Weight

15.9 kg (35.1 lb)
