Key Specifications

Output Power

16Ω: 600W×4 | 8Ω: 1200W×4 | 4Ω: 1900W×4 | 2Ω: 2500W×4
Bridge Mode: 8Ω: 3800W×2 | 4Ω: 5000W×2

Amplifier Class

Class D, Single-Ended

THD+N

0.01% @8Ω, 10W | 0.1% @4Ω, Half Power

Frequency Response

20Hz–20kHz, +0.5/-1.5 dB

S/N Ratio

112 dB (8Ω, Gain 32 dB)

Inputs / Outputs

Analog: Euroblock 6-pin ×2 (4-ch)
Digital: Dante RJ45 ×2
Speaker Out: 8-pin Euroblock ×1
Control: RJ45 ×1
AC: powerCON 20A ×1

Dante Interface

16 IN / 16 OUT, Redundant, 96/88.2/48/44.1 kHz, 24/32-bit

Protection

Over-Voltage, Over-Current, Thermal, Integrated Power Limit

Dimensions & Weight

480×88×528 mm | 16.0 kg (35.3 lb)

Power Requirements

100–240V, 50/60Hz | 1850W max, 190W idle, 9–12W standby

Operating Temp

0°C–40°C
