Key Specifications

Power Adapter

Input Voltage Range

180–264 VAC

Input Plug

European standard power cord

Output Voltage

12 VDC

Output Current

2 A

Rated Output Power

24 W

Efficiency

≥82.09%

Power Consumption (Idle)

≤0.3 W

Protection / Environmental

Protection

Overcurrent protection

Overvoltage protection

Overheating protection

Short-circuit protection

Surge protection (Common mode ±4 kV / Differential mode ±2 kV)

ESD protection (Air ±8 kV / Contact ±4 kV)

Operating Temperature

–30 °C to +40 °C (–22 °F to +104 °F)

Operating Humidity

10%–90% RH

Storage Temperature

–30 °C to +85 °C (–22 °F to +185 °F)

Storage Humidity

10%–90% RH

Physical Properties

Net Weight

0.14 kg (0.31 lb)

Gross Weight

0.17 kg (0.37 lb)

Product Dimensions

88.0 mm × 74.5 mm × 35.0 mm

Packaging Dimensions

131.5 mm × 76.5 mm × 35.5 mm

Output Cable Length

800 mm

DC Plug

Φ5.5 mm × Φ2.1 mm × 11.0 mm

Installation

Wall mount

Color

Gray
