Key Specifications

Power Adapter

Input

100–240 V, 50/60 Hz, 0.6 A

Output

12 V, 2 A (+7%, –3%)

Protection / Environmental

Protection

Surge protection

Over temperature protection

Over current protection

Voltage load protection

ESD: EN61000-4-2

±4 kV contact; ±8 kV air

Surge: EN61000-4-5

Common mode ±4 kV (12 ohms)

Differential mode ±2 kV (2 ohms)

Working Temperature

–30 °C to +70 °C (–22 °F to +158 °F)

Working Humidity

< 95% RH

Physical Properties

Weight

170 g (0.37 lb)

Dimensions (L × W × H)

104 mm × 45 mm × 33 mm

(4.09" × 1.77" × 1.30")

Installation Mode

Plane installation

Color

Black

Connectors

Input Plug

2-pin Euro plug

3-pin British plug

2-pin North American plug

Cables

AC wire: 50 cm (19.69")

DC wire: 80 cm (31.50")

DC Plug

Φ5.5 mm × Φ2.1 mm × 12 mm

(Φ0.22" × Φ0.08" × 0.47")

Certifications

Certifications

CE LVD, CE EMC

UL, FCC, DOE, CEC (varies by model)
