Key Specifications

Power Adapter

Input Voltage

100–240 VAC

Output Voltage

12 V ± 5%

Rated Output Current

1.5 A

Rated Power

18 W

Idle Power Consumption

≤0.1 W

Efficiency

≥85%

Indicator Light

1 × Green LED

Port

Input Port

North American standard 2-pin plug

Output Plug

Φ5.5 mm × Φ2.1 mm × 10.0 mm

Protection / Environmental

Protection

Overcurrent protection

Overvoltage protection

Short-circuit protection

Surge protection (Common mode ±2 kV / Differential mode ±1 kV)

ESD protection (Air ±8 kV / Contact ±6 kV)

Operating Temperature

Full load: –20 °C to +40 °C

80% load: +40 °C to +50 °C

Operating Humidity

10%–90% RH

Storage Temperature

–10 °C to +70 °C

Storage Humidity

10%–90% RH

Physical Properties

Net Weight

0.105 kg (0.23 lb)

Gross Weight

0.120 kg (0.26 lb)

Product Dimensions

95.0 mm × 34.8 mm × 28.0 mm

Packaging Dimensions

72.0 mm × 44.0 mm × 122.0 mm

Input Cable Length

350 mm

Output Cable Length

800 mm

Color

Black

Installation

Desktop mount

Certifications

Certifications

FCC
