Key Specifications

Frequency Response (-10 dB)

130 Hz - 15000 Hz

Max SPL @ 1m / 4m

100 dB / 88 dB

Coverage Angle

160°

System Sensitivity

92 dB (1W @ 4m: 80 dB)

Power Section

Power Handling

6 W (RMS), 24 W (Peak)

Protections

Thermal fuse

Recommended Amplifiers

DXT 3000, DXT 4000, DXT 7000

Transducers

1 x 5.0" Full Range

Input / Output Section

Input / Output Connectors

Ceramic screw terminals

Constant Voltage Transformer

100 V

Power Selection (Taps)

6 W, 3 W, 1.5 W, 0.75 W

Standard Compliance

Safety Agency

CE compliant, EN54-24 certified

CPR Number

0068-CPR-051/2017

Physical Specifications

Cabinet Material

Metal (Steel frame, grille, and back can)

Color

White - RAL 9016

Dimensions (Dia x D)

181 x 143 mm / 7.13 x 5.63 inches

Recessed Depth

125 mm / 4.92 inches

Cut Out Diameter

155 mm / 6.1 inches

Weight

1.35 kg / 2.98 lbs

Shipping Information

Package Dimensions

160 x 190 x 190 mm / 6.3 x 7.48 x 7.48 inches

Package Weight

1.35 kg / 2.98 lbs
