Key Specifications

Frequency Response (-10 dB)

230 Hz - 20000 Hz

Max SPL @ 1m / 4m

99 dB / 87 dB

Coverage Angle

131°

System Sensitivity

93 dB (1W @ 4m: 81 dB)

Power Section

Nominal Impedance

8 Ω

Power Handling

6 W (RMS), 24 W (Peak)

Constant Voltage Transformer

100 V

Power Selection (Taps)

6 W, 3 W, 1.5 W, 0.75 W

Transducers

1 x 6.0" Full Range

Standard Compliance

Safety Certifications

CE compliant, EN54-24 certified

CPR Number

1488-CPR-0487/W

Physical Specifications

Material

Metal cabinet, Steel grille and back cover

Color

White - RAL 9003

Dimensions (Dia x H)

230 x 137 mm / 9.06 x 5.39 inches

Cut Out Diameter

199 mm / 7.83 inches

Weight

2.03 kg / 4.48 lbs

Shipping Information

Package Dimensions

165 x 260 x 265 mm / 6.5 x 10.24 x 10.43 inches

Package Weight

2.03 kg / 4.48 lbs
