Key Specifications

Frequency Response (-10 dB)

130 Hz - 20000 Hz

Max SPL @ 1m / 4m

106 dB / 94 dB

Coverage Angle

160°

System Sensitivity

94 dB (1W @ 4m: 82 dB)

Power Section

Power Handling

20 W RMS / 80 W PEAK

Protections

Thermal fuse

Recommended Amplifiers

DXT 3000, DXT 4000, DXT 7000

Transducers

Dome Tweeter

1 x 0.75''

Woofer

1 x Coaxial 8''

Input / Output Section

Input / Output Connectors

Ceramic screw terminals

Constant Voltage Transformer

100 V

Power Selection (Taps)

20 W (500 Ω), 10 W (1000 Ω), 5 W (2000 Ω)

Standard Compliance

Safety Agency

CE compliant, EN54-24 certified

CPR Number

0068-CPR-051/2017

Physical Specifications

Cabinet Material

Metal (Steel frame, grille, and back cover)

Color

White - RAL 9016

Dimensions (Dia x D)

272 x 152 mm / 10.71 x 5.98 inches

Recessed Depth

125 mm / 4.92 inches

Cut Out Diameter

240 mm / 9.45 inches

Weight

3.42 kg / 7.54 lbs

Shipping Information

Package Dimensions

180 x 300 x 300 mm / 7.09 x 11.81 x 11.81 inches

Package Weight

3.42 kg / 7.54 lbs
